MOC-25a Modular Contactor 25A 4-Pole 2NO2NC, 230VAC Coil

MOC-25a Modular Contactor 25A 4-Pole 2NO2NC, 230VAC Coil

LS Electric MOC-25a 4-pole modular contactor with 2NO2NC main contacts (two normally open, two normally closed) and a 230 VAC coil. Rated 25 A AC-1/AC-7a and 9 A AC-3/AC-7b, it switches lighting, heating, ventilation and pump circuits from the switchboard. Mounts on 35 mm DIN rail in a 36 mm wide module to line up with MCBs and RCBOs. IP20 rated, with a mechanical life of 1,000,000 operations. Accepts MOC-AUX auxiliary contacts and 9 mm spacers.

Features and Specifications

Protection: IP20 (device). Operating range −5°C to +60°C.

Standards (& Conformities): IEC 61095, IEC 60947-4-1.

Electrical:

Rated operational voltage (Ue): 400 V
Rated insulation voltage (Ui): 500 V
Rated impulse withstand (Uimp): 4 kV
Thermal current (Ith): 25 A
AC-1/AC-7a: 25 A
AC-3/AC-7b: 9 A
Power AC-1/AC-7a: 5.4 kW single-phase 250 V, 16 kW three-phase 400 V
Power AC-3/AC-7b: 1.1 kW single-phase 250 V, 4 kW three-phase 400 V
Max. back-up fuse: 25 A

Coil:

Control voltage: 230 VAC 50/60 Hz
Inrush: 31.1 VA
Holding: 4.5 VA / 1.6 W

Dimensions and Mounting:

Width: 36 mm (2 modules)
Height × depth: 81 mm × 68 mm
Clip-on 35 mm DIN rail, ±30° from vertical

Termination:

Main: 1.5–6 mm² rigid, 1–4 mm² flexible; coil: 1.5–2.5 mm²
Tightening torque: 0.8 N·m (main and coil)

Life:

Electrical (AC-1): 300,000 operations
Mechanical: 1,000,000 operations
Max. 100 switching operations per day

Accessories: MOC-AUX side-mounted auxiliary contacts (2NO or 1NO1NC) and 9 mm MOC spacers. Fit a spacer between each contactor where the enclosure interior runs between 50°C and 60°C.

Manufacturer: LS ELECTRIC Co., Ltd.
