Home » Auer Signal » ESK Series M22 Ø30mm Panel Mount Buzzer, 230/240VAC, 85dB
ESK Series M22 Ø30mm Panel Mount Buzzer, 230/240VAC, 85dB — Auer Signal
AU-812510313 - image 2
ESK Series M22 Ø30mm Panel Mount Buzzer, 230/240VAC, 85dB — Auer Signal
AU-812510313 - image 2

Disclaimer: Images are for reference only. Refer to datasheets and drawings for accurate specifications.

Auer Signal

ESK Series M22 Ø30mm Panel Mount Buzzer, 230/240VAC, 85dB

SKU
$77.21 ex. GST $88.79 inc. GST
In stock
12 in stock across 1 warehouse
Free Shipping

Ask an expert!

Chat Email 0800 876 722
  • Material Polycarbonate
  • IP Rating IP65
  • IK Rating IK07
  • Weight (kg) 0.03
  • Operating Temp −25°C to +60°C
  • Country of Origin DE
  • Standards
    • EN 61000-6-2:2005
  • Voltage 230/240V

ESV Panel mount buzzer M22

  • Ø 30 mm panel-mount buzzer
  • Max. 85 dB (A) sound pressure
  • High degree of protection IP 65
  • Panel size Ø 22.5 mm/M22
  • 2 easily distinguishable tones
  • User-friendly connection technology
  • For industrial and general applications
  • Adapter available for M30.5 mm panel size

Standards & certifications

IP65Dust-tight · water jets IK07Impact rated CEEU conformity ULUS safety listed IEC/EN 6100062:2005 Tested standards

TROAPC's standard warranty covers all products. A 5-year warranty applies to applicable IP Enclosures products. Refer to Refunds & Returns for more information.
