Anti-Condensation Fan Heater 400 Watt
Details
Anti-Condensation Fan Heater 400 Watt
High quality Italian 400W fan assisted resistor heater for electrical enclosures.
| Features | Unit | IP-FH400 |
|---|---|---|
| Heating Capacity | W | 400 |
| Power supply | V/Hz | 230/50-60 |
| Max. current | A | 1.9 |
| Heating element type | – | Resistor |
| Thermal protection | – | Thermal cut out fuse in case of fan failure |
| Radiator | – | Extruded aluminium profile; anodized |
| Axial fan | – | Ball bearing service life 50.000 hrs at 25°C (77°F) air flow rate 35 m³/h free flow |
| Signalling | Green LED power ON | |
| Electrical connections | – | 3 screw terminals for stranded or rigid wire 2.5 mm² |
| Protection class IEC | – | Class I earthed |
| Protection degree EN60529 | – | IP20 |
| Operating temperature | °C (°F) | -25/+70 (-13/+158) |
| Storage temperature | °C (°F) | -45/+80 (-49/+176) |
| Mounting | – | Clip for mounting on DIN rail 35 mm EN50022 |
| Installation position | – | Best performance with vertical installation |
| Dimensions HxWxD | mm | 165x112x82 |
| Weight (with packaging) | kg | 0.97(1.04) |
| Conformity | – | CE – UL  |
